_____________________________________________________________________
724-746-5500 | blackbox.com Page 279
.4-5:%&$ 'yZ544	'G6QI='•'
' yZ @5-!M'$-5-&'yZ$-5-&'T,=?WbG,OT<aSTb ?=T< 'yZf3@4'?H H T Q ='
i'TX4%.!.-%]'5!!&4-'5#]'!"##&!-."#$'P("@'!"@43-&($'"#''
i'/B1*/CD*/0*0_1>'
.4-5:%&$ 'yZ544	'G6QI='yZ$"3(!&'/B1*/CD*/0*0_1>'yZ f3 @4'?HHT Q= '
C6(%(_#*900)*)0.'M (4$-$"04*-&0'$*'#"49*$6('.4-5 : %& $*.0MM-4)*-$*$6(*F"4'1*#&-P.%-&(*5(&#"$(*
M--4g__#&-P.%-&(*"(7_9"!3@&#-5-."#_.#9&X*M-@%2*C6(%(*-%(*-,#0*M-4D*6"96;T'-,"$D*$'$0%"-,#*-4)*] HECH#*-B-",-&,(*).5*$6(*
#&-P.%-&('5(&#"$(<*"4*:-%$".',-%*:(%'#(*$6(*$'$0%"-,#*,"#$()*04*$6(*#&-P.%-&(*]HECH*:-9(2*
**
!W#W%&0GB%&(.()4%D'*3-(2,1%
All console servers contain an SNMP Service (snmpd) which can provide status information on demand. snmpd is an
SNMP agent which binds to a port and awaits requests from SNMP management software. Upon receiving a request, it
processes the request(s), collects the requested information and/or performs the requested operation(s) and returns the
information to the sender.
Note: Initially only advanced console server models were equipped with an SNMP Service. With V3.0 (and later)
firmware this support was extended to all console servers. Also the MIBS were extended (and renamed for
compliance) with this firmware release.
All console servers can also be configured to send SNMP traps/messages to multiple remote SNMP Network Managers
on defined trigger events. Refer Chapter 7 for configuration details
15.5.1 Retrieving status information using SNMP
Console servers can provide serial and device status information through SNMP. This includes
- Serial port status
- Active users
- Remote Power Control (RPC) and Power Distribution Unit (PDU) status
- Environmental Monitoring Device (EMD) status
- Signal alert status
- Environmental alert status and
- UPS alert status
The MIBs in your console server are located in /etc/snmp/mibs. You also can view the current MIBs online at / and they
include:
