CONTROL OF SERVSWITCH™ DKM
107
Keyboard Commands:
<Cursor left> Cursor left Select CPU Port to the left
<Cursor right> Cursor right Select CPU Port to the right
<Cursor up> Line above Select keyboard/mouse for current User Port or
Select monitor for User Port one line above
<Cursor down> Line below Select monitor for current User Port or
Select keyboard/mouse for User Port one line below
<RETURN> Confirm selected monitor AND keyboard/mouse assignment (for CPU /
User Port at cursor position).
Attention: Switch command is executed immediately
<SPACE> Confirm selected monitor OR keyboard/mouse assignment (for CPU /
User Port at cursor position).
Attention: Switch command is executed immediately – No plausibility
check – Admissibility of configuration under responsibility of the user!
<ESC> Return to ‚Menu”
