APPENDIX G: SPECIFICATIONS
141
Appendix G: Specifications
Power Supply
Voltage
AC: 90-240VAC-0.5A-47-63Hz
Power required
230V/2000mA – 115V/4000mA
Interfaces
RJ45 (INTERCONNECT)
1000 Mbit High-speed transmission.
Wiring acc. EIA/TIA 568B Gigabit Ethernet
LC (Glass fibre)
1000 Mbit High-speed transmission.
Corresponds to Gigabit Ethernet
RJ45 – ETHERNET
(Control Port)
Standard ETHERNET access for HTTP, FTP,
TELNET
DB9 – Serial
(Control Port)
115,2 KBAUD, 8 data bits, 1 Stop bit, NO parity
Limited Hardware Handshake (DSR)
Maximum Length of CATx Interconnection Cable
CATx installation cable
140m (400ft) - AWG24 (solid cable)
CATx patch cable
70m (200ft) - AWG26/8 (stranded cable)
Type of Interconnection Cable
CATx installation cable AWG24
(solid cable)
S/UTP (Cat5) cable acc. EIA/TIA 56A, TSB 36 or
Digital STP 17-03170. Four pairs AWG 24. Wiring
acc. EIA/TIA 568A (1000BaseT).
CATx patch cable AWG26/8
(stranded cable)
S/UTP (Cat5) cable acc. EIA/TIA 56A, TSB 36 or
Digital STP 17-03170. Four pairs AWG 26/8. Wiring
acc. EIA/TIA 568A (1000BaseT).
