APPENDIX I: SERVSWITCH™ MEDIA EXTENDER
147
ServSwitch™- KVM Extender Local/ Remote Unit (CATx) – Rear View
ServSwitch™- KVM Extender Local/ Remote Unit (Fibre) – Rear View
Connect to 5V power
supply
INTERCONNECT – carries video
and data signals – connect to Local/
Remote Unit with CATx- cable
Connect to 5V power
supply
Connect to Local/ Remote
Unit with Fibre Cable
