ServSwitch™ DKM
150
ServSwitch™- KVM Local Unit with 2x USB-HID + 4x USB-2.0
ServSwitch™- KVM Remote Unit with 2x USB-HID + 4x USB-2.0
To CPU: DVI
Connect to CPU:
USB
Connect to local
DVI- monitor
Remote DVI- monitor port–
Connect to remote console
monitor
Remote keyboard/
mouse port
Connect to CPU:
secondary USB
4x Remote secondary
USB-2.0 port
