SERVSWITCH™ DKM CONFIGURATION
39
6.1.1.3 General frame structure of the OSD:
6.1.1.4 Upper Status Area
(left corner)
Upper status area
Work area
Lower status area
Name of the current
console port
Operating mode of the
current console port
Name of the user
currently logged-in
Name of the current
menu
