75
LEGACY
SealPro II (AAM2857) Assembly,
Optional Sealer II Spring Add-on Kit 1 Row
AAM2857 OPTIONAL SEALPRO II SPRING ADD-ON KIT 1 ROW
BOM ID Qty Item No Description
1 2 AM2488 CLEVIS,
SEALER SPRING, UPPER
2 2 AM2489 CLEVIS,
SEALER SPRING, LOWER
3 2 AM2490 TUBE, UPPER SPRING
4 2 AM2491 BUSHING, SPRING COLLAR
5 2 AM2492 TUBE, SPRING GUIDE
6 2 AP2997W SPRING, 1.75” OD X 1.313” ID X 6.00” OAL
7 2 AP3116 TUBE PLUG
8 4 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
9 4 BP3043 WASHER, LOCK, 1/2”, PLATED
10 8 BP3050 WASHER, FLAT, 1/2”, PLATED
11 4 BP3126 HEX CAP SCREW, 1/2”-13 X 1-1/2”, GRADE 5, PLATED
12 2 BP3129 HEX CAP SCREW, 1/2”-13 X 3”, GRADE 5, PLATED
13 2 BP3130 HEX CAP SCREW, 1/2”-13 X 3-1/2”, GRADE 5, PLATED
14 4 BP3244 NUT, HEX LOCK, 1/2”-13, PLATED
