LEGACY
GDI 200 With Pump Distribution (Rear Mount)
Parts (Bundle 20200119)
BOM ID Qty Item No Description
1 1 55000171 KIT, HEAT EXCHANGER, REAR OF FRAME MOUNT
2 1 AAM2089 ASSEMBLY, SPRING ADJUSTER
3 1 AAM2707 ASSEMBLY, HUB & SPINDLE, 511 HUB, 1-3/4” X 13”
4 1 AAM2750 WHEEL 5.00-15.4, 4 PLY 15 X 5 X 5, WHITE, 4 HOLE
5 1 AM2021 ADAPTER PLATE & HUB
6 1 AM2165 BRACKET, ROTARY TENSION ARM MOUNT
7 1 AM2180 UNIVERSAL PUMP MOUNTING PLATE
8 1 AM2181 GROUND DRIVE WHEEL FRAME
9 1 AM3326 BRACKET, PUMP EXTENSION
10 1 AM4856 BRACKET, MOUNTING, 6”
11 1 AP2190 SPROCKET, 5060 X, WITH HUB, 1’’ ROUND BORE, 1/4’’ KEYWAY
12 1 CCP2755 HEAT EXCHANGER ASSEMBLY
13 1 CCP2756 PUMP AND VALVE ASSEMBLY
14 1 PKG00012 PACKAGE, LARGE HARDWARE FOR 20200090
14A 1 AP2382 SPROCKET, IDLER, 15T #50 CHAIN, WITH CLEVIS ADAPTER
14B 2 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
14C 2 BP3035 WASHER, LOCK, 3/4”, PLATED
14D 1 BP3070 PIN, 3/4” X 2”
14E 1 BP3239 TENSIONER, RT1002
14F 1 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
14G 1 BP3502 PIN, 3/4” X 4-1/2”
14H 1 BP3510 PIN, 1” X 10”, PLATED
14I 1 CM2248 CHAIN, ROLLER, #50, 128 PITCH
14J 2 CP2310 1’’ HOSE BARB
14K 1 CP2474 REDUCER BUSHING 1” MP X 1/4” FP,
14L 1 CP2479 PLUG, SQUARE HEAD, 3/4” NPT
14M 1 CP2480 PLUG, 1’’
14N 1 CP2522 NIPPLE, HEX, 1-1/4” NPT, 3000 PSI TRIVALENT
14O 1 CP2870 STRAINER, NH3, 1-1/4” FPT, 20 MESH, CONTINENTAL
14P 2 CP2874 HOSE BARB, 1/2’’ X 3/4’’
14Q 1 CP2875 ELBOW, STREET, 1-1/4” NPT 45 DEGREE
14R 2 CP5043 KNIFE VAPOR TUBE 3/4’’ HOSE, WELD-ON
14S 1 DP3999 CROSS 1” FORGED
14T 1 DP4034 NIPPLE, CLASE, 1’’EXTRA HEAVY
14U 6 DP4086 CABLE TIE 11-3/8”
14V 6 DP4296 CABLE TIE 33”
14W 2 DP4397 SWIVEL, 1-1/4” MP X 1-1/4” FP
15 1 PKG00011 PACKAGE, SMALL HARDWARE FOR 20200090
15A 1 AP2103 CONNECTOR LINK #50 CHAIN
15AA 1 AP2103-BAR CONNECTOR LINK #50 CHAIN
15AB 1 AP2103-CONNECTOR CONNECTOR LINK #50 CHAIN
15AC 1 AP2103-LINK CONNECTOR LINK #50 CHAIN
15B 1 BM3527 1/4’’ X 1/4’’ X 1” KEY
15C 11 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
15D 12 BP3002 WASHER, LOCK, 3/8”, PLATED
15E 3 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
15F 16 BP3015 WASHER, FLAT, 3/8”
15G 8 BP3038 NUT, HEX, 5/8”-11, GRADE 2
15H 4 BP3039 WASHER, LOCK, 5/8”, PLATED
15I 4 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
15J 4 BP3043 WASHER, LOCK, 1/2”, PLATED
15K 8 BP3115 HEX CAP SCREW, 3/8”-16 X 2”, GRADE 5, PLATED
15L 1 BP3116 HEX CAP SCREW, 3/8”-16 X 3, GRADE 5, PLATED
15M 4 BP3126 HEX CAP SCREW, 1/2”-13 X 1-1/2”, GRADE 5, PLATED
15N 3 BP3500 PIN, HAIR CLIP, 3/16”
15O 2 CP2313 HOSE CLAMP, WORM GEAR, 1/4”- 5/8” TUBING, STAINLESS STEEL
15P 6 CP2314 HOSE CLAMP, WORM GEAR, 1/2”- 1” TUBING, STAINLESS STEEL
16 1 PKG00025 PACKAGE, ORIFACE FITTING HARDWARE
16A 1 CP2541 ORIFICE PLATE #4916-63 JET STREAM
16B 1 CP2545 ORIFICE PLATE #4916-95 JET STREAM
16C 1 CP2557 ORIFICE PLATE #4916-35 JET STREAM
16D 1 CP5044 NOZZLE BODY, STEEL
16E 1 CP5045 NUT, SPRAY TIP
16F 1 CP5046 HOSE BARB INSERT, 3/8”, STAINLESS STEEL
17 1 CCM2325 1/4’’ Y-STRAINER
17A 1 AM3338 BRACKET, ORIFICE STRAINER MOUNT
17B 3 CP2308 HOSE BARB
17C 2 CP2313 HOSE CLAMP, WORM GEAR, 1/4”- 5/8” TUBING, STAINLESS STEEL
17D 1 CP2441 NIPPLE, 1/4’’ MP, STAINLESS STEEL
17E 1 CP2463 STRAINER, NH3, 1/4’’ FPT, 60 MESH, KECKLEY STYLE B
17F 1 CP2464 PLUG, 3/8’’ MP
18 1 CP25009 HOSE, EVA, 3/8” X 8’
19 2 CP25025 HOSE, EVA, 3/4” X 14’-8” (CP2515 CUT 2 EA.@14’-8”)
20 2 CP2895 HOSE, NH3, 1-1/4” NPT X 60” HIGH PRESSURE CRIMP
21 1 CP3001 HOSE, EVA, 1” REINFORCED X 180” with TIE & TAG
