Supply voltage and frequency ®
200-208 V
50 Hz
200-208 V
60 Hz
230 V
60 Hz
380-415 V
50 Hz
460 V
60 Hz
iH80
Full load (A) 14.4 14.9 14.4 7.2 7.2
HCDP motor rating (kW) 2.9 3.5 3.5 2.9 3.5
Maximum power input
to pump motor (kW)
3.65 4.48 4.48 3.65 4.48
iH600
Full load (A) 26.2 26.7 26.1 13.1 13.0
HCMB motor rating (kW) 2.2 2.6 2.6 2.2 2.6
Maximum power input to
both pump motors (kW)
6.51 7.8 7.8 6.51 7.8
iH1000
Full load (A) 26.2 26.7 26.1 13.1 13.0
HCMB motor rating (kW) 2.2 2.6 2.6 2.2 2.6
Maximum power input to
both pump motors (kW)
6.51 7.8 7.8 6.51 7.8
Table 2-2 - Full load current ratings
2.7 Gas system
Note: Once you have connected your nitrogen supply and adjusted the nitrogen supply pressure, for
optimum performance of the pressure regulator, we recommend that the stability of your nitrogen
supply is such that the supply pressure remains within ± 20 psi of the adjusted pressure.
Nitrogen supply pressure range 20 to 100 psig (2.4 to 7.9 bar absolute,
2.4 x 10
5
to 7.9 x 10
5
Pa)
Nitrogen supply quality Clean, dry, particles < 0.01µm
Flow rates (with nitrogen supply
capacity of 100 slm) See Table 2-3
Pressure transducer accuracy ± 0.6 psi (± 4.1 x 10
-2
bar, ± 4.1 x 10
3
Pa)
at 6 psig (1.4 bar absolute, 1.4 x 10
5
Pa)
Flow transducer accuracy ± 3.0 slm (± 5 x 10
3
Pa.ls
-1
)
iH Dry Pumping Systems 2-15
