3.21.5 Cable connections
Connect the cables from the disconnect box to the appropriate locations as follows:
1. Punch out the EMO cable outlet hole (2) on the bottom of the disconnect box. See Figure 3-14.
2. Connect the cable cores to terminals 1 and 2 of the disconnect box. See Figures 3-12 and 3-13.
3. Plug the six way XLR connector into the Tool Interface Module of the iH system. See Figure
1-5.
4. See Section 3.22 for photohelic switch/gauge connections.
5. Close the Disconnect box door and secure it using a flat bladed screwdriver.
iH Dry Pumping Systems 3-35
Figure 3-13 - Disconnect box sub-panel general arrangement: key
1. From customer supply
2. Neutral terminal
3. Ground bar
4. Main Contactor C1
5. 3 Second Brown-Out time delay relay TDR1
6. Terminals 1-6
7. Photohelic Gauge circuit breaker CB1
8. Fused mains disconnect F1 through F3
9. 24 VAC control circuit transformer T-1 and fuses F4 through F6
