2.10 Resource conservation
Measures have been taken in the design of the iH system to conserve the environment, as
advised by ISO14001 - Environmental management systems.
Packaging materials may be recycled.
Power consumption has been minimised.
Lubrication for life has been incorporated into the pump design.
No pump parts require cleaning for maintenance.
Materials used in manufacture of the pump may be recycled on completion of its useful life.
2.11 Default setpoints
The default setpoints are shown in Tables 2-4 to 2-6. Where there is an 'ADJ' (adjust) entry in
these tables, this specifies that the setpoints are usually not used and the default setpoint is
preset so that no warning or alarm condition could result from sensor readings. If required
you can adjust these 'ADJ' setpoints for your application, so that suitable warnings and
alarms can be generated: refer to Section 5.3.
Parameter Unit
Default setpoint values
Low alarm
Low
warning
High
warning
High alarm
HCDP power consumption kW ADJ 0.0 4.0 4.7
HCMB power consumption kW ADJ 0.0 2.9 3.6
Table 2-4 - Electrics box default setpoints
Parameter Unit
Default setpoint values
Low alarm
Low
warning
High
warning
High alarm
HCDP pump temperature
o
C ADJ ADJ 168 177
HCDP motor cooling-water
return temperature
o
C ADJ ADJ 45 ADJ
HCMB600 pump temperature
o
C ADJ ADJ 115 125
HCMB1000 pump
temperature
o
C ADJ ADJ 165 170
Exhaust gas temperature
o
C ADJ ADJ 220 ADJ
Table 2-5 - Electronics module default setpoints
iH Dry Pumping Systems 2-17
