RF earth (ground) stud (6) If required, use this to make additional RF earth
(ground) connections: refer to Section 3.16.4.
Refer to Figure 1-6, detail A or B. The bottom panel of the Electrics Box has the following
cables and connectors:
Electrics and Control Loom (17) This is used to provide power, measurement signals and
control signals to the Electronics Module.
HCDP electrical supply
cable (18)
This is used to connect the electrical supply from the
Electrics Box to the HCDP pump.
HCDP thermistor cable (19) This is used to connect the output of the thermistor in the
HCDP pump to the Electrics Box.
1-14 iH Dry Pumping Systems
25. Emergency stop switch
26. RJ12 connector for PDT
27. Not used
28. HCMB temperature sensor
29. Not used
30. Exhaust temperature sensor *
31. HCDP pump-body temperature sensor
32. Control PL3 connector
33. Gas module PL4 connector
34. Water flow-switch
35. RS485
36. Dashboard PL1 connector
37. Sensors PL2 connector
38. Not used
39. Solenoid-valves (6 off)
40. Pressure transducers (2 off)
41. Mass flow transducer
42. Dashboard LEDs
43. Not used
44. 4-way XLR connector for PDM
45. Active Gauge connector *
46. Lower rear bulkhead panel
47. d.c. electrical supply fuse holder
48. Active gauge cable connector
49. Sensor connector
50. Inverter
1. Electrics Box
2. Gas Module
3. Electronics Module
3A. Control SMA
4. Pump Display Terminal
5. External electrical supply
6. Electrical supply connector
7. Protective earth (ground) stud
8. Exhaust Gas Management interface
9. Tool Interface Module connector
10. Pump Display Module *
11. iH Tool Interface Module fuse holder
12. Emergency stop fuse holder
13. HCDP electrical supply
14. HCDP motor terminal-box
15. HCDP motor thermistor cable
16. HCMB electrical supply
17. HCMB motor terminal-box
18. HCMB motor thermistor cable
19. RF earth (ground) stud
20. Cooling-fan connector
21. iTIM
22. iTIM connector
23. Pump shut-down thermistor
24. Not used
* Optional accessory
Figure 1-4 - Schematic diagram of the iH1000 electrical system: key
