3.7.2 iH600/iH1000 systems
The iH600 and iH1000 systems are supplied with both the HCDP and HCMB pumps filled
with oil. However, we recommend that you check the HCDP and HCMB oil-levels as
described below.
1. Check the HCDP pump oil-level: refer to Section 3.7.1.
2. Refer to Figure 1-1. Check that the oil-level is between the MAX and MIN marks on the bezel
of the HCMB oil-level sight-glass (5):
•
If the oil-level is above the MAX mark, drain excess oil from the pump as described in
Section 6.10 until the oil-level is correct.
•
If the oil-level is below the MIN mark, fill the pump with oil until the oil-level is correct, as
described in Section 6.10.
3.8 Install or replace the pump display terminal and optional accessories
(if necessary)
3.8.1 Install the pump display terminal
CAUTION
It is imperative that the Pump Display Terminal is stored in the recess after installation or
use. Placing it on a hot surface such as on top of the enclosure may adversely affect the
long-term reliability of the terminal.
1. Unpack and inspect the Pump Display Terminal.
2. Refer to Figure 3-6. Remove the blanking panel (1) from the dashboard (2).
3. Fit the connector (4) on the end of the cable (7) to the Pump Display Terminal connector (6) in
the recess (5) in the dashboard.
Note: The Pump Display Terminal connector (6) is intended for use by the Pump Display Terminal only,
and should not be mistaken for a Portable Personal Computer port .
4. Place the coiled cable (7) in the recess, then place the Pump Display Terminal(8) in position in
the recess (5).
3.8.2 Install optional accessories
Note: Some accessories can only be factory fitted (see Section 8): you will have ordered these accessories
when you ordered your iH system, and the accessories will be supplied fitted to your iH system.
Install optional accessories (listed in Section 8) as described in the instructions supplied with
the accessory.
iH Dry Pumping Systems 3-11
