Warning message Advisory message Meaning/recommended action
WARNING 17601 SEE MANUAL
The inverter on an iH1000 system has
experienced a transient power supply problem,
or there is a recoverable fault.
WARNING 17701 SEE MANUAL
The HCMB pump stator temperature is
> 165
o
C, and the HCMB pump speed has been
reduced to 1200 r.min
-1
. The warning
condition will be removed and the HCMB
pump speed will increase to 6000 r.min
-1
again
when the pump stator temperature has fallen
to 150
o
C.
Table 6-1 - Warning messages (continued)
Alarm message Advisory message Meaning/recommended action
ALARM 101
STOP ACTIVATED
The emergency stop switch has been pressed
or a safety sensor connected to the emergency
stop circuit has operated (or your remote
emergency off circuit has operated) to shut
down the iH system. Note that the message
will remain on the display until you restart the
pumping system.
ALARM 101
Refer to the recommended actions for error
number 101: see Table 6-1.
ALARM 210
Refer to the recommended actions for error
number 209: see Table 6-1.
ALARM 212
Refer to the recommended actions for error
number 211: see Table 6-1.
ALARM 310
DP CURRENT LOW
OPEN CIRCUIT
CHECK CONNECTION
Refer to the recommended actions for error
number 309: see Table 6-1.
ALARM 312
DP CURRENT HIGH
LEAK/DEBRIS
SERVICE PUMP
Refer to the recommended actions for error
number 311: see Table 6-1.
ALARM 410
DP POWER LOW
OPEN CIRCUIT
CHECK CONNECTION
Refer to the recommended actions for error
number 409: see Table 6-1.
ALARM 412
DP POWER HIGH
LEAK/DEBRIS
SERVICE PUMP
Refer to the recommended actions for error
number 411: see Table 6-1.
ALARM 512
The pump-motor has tripped out because the
motor windings are too hot: either the
cooling-system has failed or the motor
overloaded. Either of these faults should have
been identified before shut-down, so either
there are two separate faults (for example,
cooling-water supply failure and thermocouple
circuit failure) or the thermistor circuit has
failed: contact your supplier or Edwards.
6-26 iH Dry Pumping Systems
Table 6-2 - Alarm messages
