Use the following procedure to unpack and inspect the iH system.
1. Place the pallet in a convenient position with a fork-lift truck or a pallet truck.
2. Remove the staples which secure the cardboard box to the pallet, then remove the cardboard
box. Open the top of the foil bag which encloses the iH system.
3. Check that you have received the items listed in Table 3-2. If any of these are missing, notify
your supplier within three days.
Qty Description Check (✓)
1
1
iH dry pumping system
Pump Display Terminal
❑
❑
Fitting-kit which contains the following:
1
1
1
1
1
1
1
1
2
Inlet 'O' ring
✝
Cooling-water quick-release connectors (pair)
NW40 trapped 'O' ring
NW40 clamp
Nitrogen pipeline fitting
Module connector terminator plug
Emergency stop switch guard *
Electrical supply connector
Lifting Bolt Hole Plugs
#
❑
❑
❑
❑
❑
❑
❑
❑
❑
* If required, fit this over the emergency stop switch to prevent inadvertent operation of the switch.
✝ Supplied with the iH80 only.
# Supplied with iH80 and iH600 only
Table 3-2 - Checklist of components
4. Refer to Figure 3-1. Remove the nut and washer (2) which secures each of the four seismic
brackets (5) to the blocks (4) on the pallet. Retain the nuts and washers for future use.
5. Refer to Figure 3-2. Use suitable lifting-equipment attached to the lifting bolts (1) to remove
the iH system from its pallet. Do not try to lift the iH system by hand (see Section 2 for the
mass of the iH system).
6. Inspect the iH system. If the iH system or any other item is damaged, notify your supplier
and the carrier in writing within three days; state the Item Number of the iH system together
with your order number and your supplier's invoice number. Retain all packing materials
for inspection. Do not use the iH system if it is damaged.
7. If the iH system is not to be used immediately, replace the packing materials. Store the iH
system in suitable conditions as described in Section 7. If you will use the iH system
immediately, continue at Step 8.
8. Refer to Figure 3-1. If you do not want to use the seismic brackets to prevent inadvertent
movement of the iH system (see Section 3.6), undo and remove the two cap -head screws and
washers (6) which secure each of the four brackets (5) to the sides of the iH system, then
remove the brackets. Retain the brackets, cap-head screws and washers for future use.
3-4 iH Dry Pumping Systems
