Displays the available airports in the chart clip. Selection of an airport (green
diamond) displays the Terminal Charts page for that airport.
Selection displays the Edit Clip page.
Selection displays the Chart Utilities page.
TERMINAL CHARTS - EDIT CHART CLIP Page
Selection –
• Box (empty) - chart is not displayed in the chart clip
• Box (green check mark) - chart is included in the chart clip
4
CHART CLIP AIRPORTS Field
5
EDIT CLIP Soft Key
6
CHART UTILITIES Soft Key
1
Selection Box
DSPL
DSPL
PWR
XFRPGDNPGUPMENU ENTER
BRT
DIM
TERMINAL CHARTS
1/1
EDIT CHART CLIP
BGSF - ORIGIN
Current Mode: Night
CHART NOTAMS
AIRPORT, AIRPORT
INFO, TAKE-OFF MNMS
(10-9)
MKR LOC DME RWY 10
(11-1)
NDB DME OR NDB RWY
10 (16-1)
CHART TYPES
ALL
DAY
MODE
CANCEL
CHANGES
COMPLETE
4
1
2
3
