787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Automatic Flight -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
4.10.16 D615Z003-TBC
PFD and HUD Flight Mode Annunciations (FMAs)
Note: When first engaged/activated, AFDS/autothrottle mode changes are
emphasized for 10 seconds by a green box drawn around the mode. A
change to the AFDS mode NO AUTOLAND is also emphasized by box
(amber on the PFD and green on the HUD).
Note: When autopilot is engaged, a horizontal line is drawn through the
appropriate ENGAGED pitch or roll mode when a flight mode fault is
detected (amber on the PFD and green on the HUD).
Displayed (green) –
Displayed (green) –
Displayed (green) –
1
Autothrottle Modes (Active)
• THR
• THR REF
• HOLD
• IDLE
• SPD
2
AFDS Roll Modes (Engaged)
• HDG HOLD
• HDG SEL
• LNAV
• LOC
• ROLLOUT
• TO/GA
• TRK SEL
• TRK HOLD
[Option – Bank angle hold]
• ATT
• B/CRS
•FAC
[Option – HUD low visibility takeoff]
• HUD TO/GA
3
AFDS Pitch Modes (Engaged)
HEAD-UP DISPLAY PRIMARY FLIGHT DISPLAY
HOLD
LNAV VNAV
LOC
G/S
A/P
HOLD LNAV VNAV
LOC G/S
A/P
654 4 65
1
2
3 1
2
3
