787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Communications -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
5.10.4 D615Z003-TBC
Push – Selects desired communication tuning mode page for display
• VHF – VHF Radio Key
[Option – HF radios]
• HF – HF Radio Key
[Option – SATCOM]
• SAT – SATCOM Key
• CAB – Cabin Interphone Key
Push –
• selects function line to be updated
• moves data from scratchpad to selected line
Push –
• transfers the STBY frequency to the ACTIVE frequency and tunes the
selected radio to the new active frequency
• transfers the ACTIVE frequency to the STBY frequency
Push – puts selected character in scratchpad.
Push – clears last scratchpad character or scratchpad message.
Push and hold – clears all scratchpad data
• displays CLEAR if on VHF, HF, CABIN INTERPHONE (main page) or
ALTN NAV page
• displays CLEAR PAGE if CLEAR is already displayed on STORED VHF
or HF frequency pages
• displays CLEAR ALL if CLEAR is already displayed on CABIN
INTERPHONE (main page)
Active when a list (- N/X) number is displayed next to the STBY radio title.
Push (Up) – moves up in the stored frequency list for VHF and HF radios.
Push (Down) – moves down in the stored frequency list for VHF and HF radios.
Push – selects the MENU page for display of
• SYS POWER (surveillance system power)
• ALERT / XPDR (transponder) CTRL (control)
1
Mode Select Keys
2
Line Select Keys
3
Frequency Transfer (XFR) Switch
4
Numeric Keypad
5
Clear (CLR) Key
6
Standby (STBY) Frequency STEP Control
7
MENU Key
