Communications -
MFD Communications Functions
Copyright © The Boeing Company. See title page for details.
5.40.14 D615Z003-TBC
Displays current time.
For new messages – time the message is received.
For review messages – time the message is received or sent.
Displays message title information.
Only displayed for review list boxes.
The appropriate status indicator is displayed.
Message Display Format
A typical message display format is shown. Messages selected from a list are
displayed in this format.
Note: Selection of a main menu item exits the message page.
1
Current Time
2
Message Time
3
Message Title
4
Message Status
REVIEW
COMPANY
ATC
MANAGER NEW MESSAGES
FLIGHT
INFORMATION
1848z RECEIVED
VHF-VOICE CONTACT
ACCEPTED
WEATHER
ATIS
DISPLAYED
DISPLAYED
1842Z
1832Z
1820Z
1
2
3
4
June 16, 2008
