787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Communications -
MFD Communications Functions
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 5.40.15
For downlink messages – current time.
For new messages – time the message is received.
For review messages – time the message is received or sent.
Displays message title information.
Only displayed for review messages.
The appropriate state indicator is displayed.
Located between the title and the keys.
Exclusive and Nonexclusive Select Keys
Manager and new message pages can contain select keys to activate features.
Pushing the cursor select switch when the key is highlighted makes the selection.
A second selection of a nonexclusive key toggles to the deselected state.
1
Message Time
2
Message Title
3
Review State
4
Message Content
COMPANYATC
REVIEW MANAGER NEW MESSAGES
GATE INFORMATION1233z
Flight: XX127
ACCEPTED
FLIGHT
INFORMATION
Gate: B1
ETA: 1245Z
1
3
4
2
June 16, 2008
