Communications -
MFD Communications Functions
Copyright © The Boeing Company. See title page for details.
5.40.32 D615Z003-TBC
ATC Logon/Status
The ATC LOGON/STATUS page allows entry of the desired ATC facility for
establishment of a datalink connection.
The SEND key is displayed after all logon entries are completed. Selecting the
SEND key displays SENDING status during logon transmission. Five seconds
after the logon status changes to SENT, the page is exited.
0039z ATC LOGON/STATUS
LOGON TO:
FLIGHT NUMBER:
ORIGIN:
DESTINATION:
ATC CONNECTION:
ACTIVE CENTER:
NEXT CENTER:
ADS STATUS: ARMED
NOT ESTABLISHED
ATC
FLIGHT
INFORMATION
COMPANY
REVIEW
MANAGER
RETURN
EXIT
SEND
ADS
MANAGER
NEW MESSAGES
1
2
3
5
6
7
8
4
June 16, 2008
