Flight Controls -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 9.10.7
DOWN (detent) – all spoiler panels are retracted.
ARMED – the auto speedbrake system is armed.
UP – the required spoiler panels extend to their maximum in–flight or on–ground
position (intermediate positions can be selected).
1
Speedbrake Lever
CONTROL STAND
1
DOWN
ARMED
UP
