787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.10.9
PFD Rising Runway Indications
[Option – Rising runway]
Displayed below 2,500 feet altitude when the localizer pointer is in view for both
front and back courses.
Moves toward the airplane symbol below 200 feet radio altitude.
The stem of the rising runway symbol flashes when localizer deviations cause the
diamond to flash.
1
Rising Runway
10 10
20 20
860
1
February 13, 2009
