Vertical Situation Display (VSD)
The VSD presents a profile view of the airplane and its environment. It is located
on the bottom third of the ND. Terrain, waypoint, and other information shown
within the cyan dashed lines (VSD corridor) on the ND is shown in profile on the
VSD.
