ND Failure Indications and Flags
ND Failure Messages
The amount of map information sent to the primary display system is too great to
display.
The selected range and range of display information disagree.
Map information is removed.
ND Failure Flags
Dashes replace numbers if there is no computed information. Failure flags replace
symbols or failure messages are displayed, as appropriate. Flag location varies,
depending on the ND mode selected.
1
Excess Data
2
MAP/WXR Range Disagree
MAP RANGE DISAGREE
WXR RANGE DISAGREE
MAP/WXR RANGE DISAGREE
EXCESS DATA
TERR RANGE DISAGREE
MAP/TERR RANGE DISAGREE
NAVIGATION DISPLAY
1
2
