787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.10.37
MFD Messages
The number of instances requested for a display format exceeds the maximum
available.
Maximum number of instances for each format:
• SYS (2 per side, independent)
• CDU (1 per side, independent)
• INFO (2 per side, independent)
• CHKL (1 per side, synchronized)
• COMM (1 per side, independent)
• ND (1 per side, independent)
The DU is operating normally, but the display format is not available.
1
Select MFD
2
Display Format Not Available
AIRPORT MAP DATABASE
FEB02MAR02/07
<ACTIVE>
JAN01FEB01/07
INFO PAGE
SELECT MFD
SYS NOT AVAILABLE
CDU NOT AVAILABLE
INFO FUNCTION NOT AVAILABLE
CHKL NOT AVAILABLE
COMM NOT AVAILABLE
ND NOT AVAILABL
E
1
2
MULTIFUNCTION DISPLAY
February 15, 2010
