L or R indicates that the left or right EFIS control panel is the barometric setting
reference for the autopilot or flight director (the same indication is displayed on
both HUDs).
Displayed when a flight director switch is in the ON position or the autopilot is
engaged:
• F/D – one turned on and one not on determines L or R
• F/D – both on – L is displayed
• A/P – first one pushed on determines L or R
4
Autopilot/Flight Director Barometric Source
5
Preselected Barometric Setting
6
QFE
7
Uplinked Barometric Setting
