Boeing 787-8 - Page 979

787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Navigation Displays
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.40.11
[Option – Dual ADF]
[Option – Dual ADF]
Map
Symbol Name ND Mode Remarks
VOR (G) selection MAP, MAP
CTR
Located lower left or right
corner. Represents
positions selected on the
MAP or MAP CTR
drop-down menu.
ADF (C) selection mini-map Located lower left or right
corner. Represents
positions selected on the
MAP or MAP CTR
drop-down menu.
VOR frequency or
identifier (G),
MAP, MAP
CTR
Frequency is displayed
before identifier is
decoded. Decoded
identifier replaces the
frequency. For VORs,
small size characters
indicate only DME
information is being
received.
ADF frequency or
identifier (C)
mini-map
DME distance (G) MAP, MAP
CTR
Indicates DME distance to
the referenced navaid.
Symbol Name ND Mode Remarks
Airplane symbol (W),
lateral path deviation
(W), lateral ANP/RNP
values (G, A)
MAP, MAP
CTR
Current airplane position is
at the apex of the triangle.
Displays lateral path
deviation distance. When
ANP exceeds RNP, the
ANP/RNP labels and
values are displayed in
amber.
Airplane symbol (W) mini-map Current airplane position is
at the apex of the triangle.
VOR L, R
ADF L, R
SEA
116.80
OR
BF
520
OR
DME
24.6
1.2 R
RNP
1.00
ANP
0.04
February 15, 2010
