787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Navigation Displays
Copyright © The Boeing Company. See title page for details.
10.40.26 D615Z003-TBC
Radar
Symbol Name ND Mode Remarks
Weather radar (WXR)
test mode (C) (A)
MAP, MAP
CTR,
mini-map
Weather radar system is
selected on the EFIS
control panel or MAP mode
drop-down menu. (Weather
Radar, Ch. 11, Sec. 10)
WXR precipitation
only mode (C)
WXR and turbulence
mode (C)
WXR receiver gain
(C)
Mode used with
down–tilt when
ground mapping (C)
WXR antenna tilt (C)
WXR system failure
(A)
WXR receiver
transmitter failure (A)
WXR antenna failure
(A)
WXR control panel
failure (A)
WXR loss of attitude
data (A)
WXR calibration fault
(A)
TEST
WX
WX+T
-3 to +3
MAP
+15.0
to
-15.0
WXR
FAIL
RT
ANT
CONT
ATT
WEAK
