13.4 Frequency Reference Channel
The various functions for the defining the reference frequency are connected via the
frequency reference value channel. The
Reference Frequency Source 475 determines
the additive assignment of the available reference value sources depending on the
hardware installed.
Reference frequency source 475 Function
1 - Abs. Analog Value MFI1A
Reference value source is the multifunctional in-
put 1 in
Operation Mode 452 - Analog signal.
10 -
Abs. Val. Fixed Frequency
(FF)
The fixed frequency according to the
Fixed Fre-
quency Change-Over 1
66 and Fixed frequency
change-over 2
67 as well as the current data set.
11 - Abs. Value MFI1A + FF Combination of the operation modes 10 and 1.
20 - Abs. Value Motorpoti (MP)
Reference value source is the function
Frequency
Motorpoti Up
62 and Frequency Motorpoti
Down
63.
21 - Abs. Value MFI1A + MP Combination of the operation modes 20 and 1.
30 -
Abs.Val. Speed Sensor 1
(F1)
The frequency signals in
Operation Mode 490
are evaluated as a reference value.
31 - Abs. Val. MFI1A + F1 Combination of the operation modes 30 and 1.
32 -
Abs. Repetition Frequency
Input (F3)
The frequency signal on the digital input accord-
ing to
Operation mode 496 for the repetition
frequency input.
33 - Abs. Val. MFI1A + F3 Combination of operation modes 1 and 32.
40 - Abs. Value Motorpoti (KP)
The KP 500 control unit is the reference value
source, with keys â–² for increasing the frequency
and â–¼ for reducing the frequency.
41 - Abs. Value MFI1A + KP Combination of the operation modes 40 and 1.
80 -
Abs. Val.
MFI1A + FF + KP + F1 + F3
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 40, 32
(+ analog input extension module)
1)
.
81 -
Abs. Val.
MFI1A + FF + KP + F1 + F3
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 40,
30, 32
(+ analog input extension module)
1)
.
82 -
Abs. Val.
MFI1A + FF + KP + F3
+ (F2)
2)
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 40, 32
(+ absolute amount speed sensor 2 (F2))
2)
(+ analog input extension module)
1
.
89 -
Abs. Val.
MFI1A + FF + KP + F1 + F3
+ (F2)
2)
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 40,
30, 32(+ absolute amount speed sensor 2 (F2))
2)
(+ analog input extension module)
1)
.
90 -
Abs. Val. MFI1A + FF + MP
+ F3 + (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 32
(+ analog input extension module)
1)
.
91 -
Abs. Val. MFI1A + FF + MP
+ F1 + F3+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20,
30, 32 (+ analog input extension module)
1)
.
92 -
Abs. Val. MFI1A + FF + MP
+ F3 + (F2)
2)
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 32
(+ absolute amount speed sensor 2 (F2))
2)
(+ analog input extension module)
1)
.
99 -
Abs. Val.
MFI1A + FF + MP + F1 +
F3 + (F2)
2)
+ (EM-S1INA)
1)
Combination of the operation modes 1, 10, 20,
30, 32 (+ absolute amount speed sensor 2 (F2))
2)
(+ analog input extension module)
1)
.
101 to 199 Operation modes with signs (+/-).
1)
The reference value source is only available if an extension module with analog input is con-
nected. For information, refer to the extension module operating instructions.
2)
The reference value source is only available if an extension module with speed sensor input is
connected. For information, refer to the extension module operating instructions.
