Operating Instructions ACTIVE 06/0720
20 Operating Instructions ACTIVE 06/07
3.5 ACT 401 (0.55 up to 4.0 kW, 400 V)
Type
ACT 401
-05 -07 -09 -11 -12 -13 -15 -18
Output motor side
Recommended shaft output
P kW 0.55 0.75 1.1 1.5 1.85 2.2 3.0 4.0
Output current
I A 1.8 2.4 3.2 3.8
3)
4.2 5.8 7.8 9.0
3)
Long-term overload current (60 s)
I A 2.7 3.6 4.8 5.7 6.3 8.7 11.7 13.5
Short-term overload current (1 s)
I A 3.6 4.8 6.4 7.6 8.4 11.6 15.6 18.0
Output voltage
U V Maximum up to mains voltage, three-phase
Protection
- - Short circuit / earth fault proof
Rotary filed frequency
f Hz 0 ... 1000, depending on switching frequency
Switching frequency
f kHz 2, 4, 8, 12, 16
Output brake resistor
min. brake resistor
R Ω 300 300 300 300 136 136 136 92
Recommended brake resistor
(U
dBC
= 770 V)
R Ω 930 634 462 300 300 220 148 106
Input, mains side
Mains current
2)
3ph/PE
I A 1.8 2.4 2.8
1)
3.3
1)
4.2 5.8 6.8
1)
7.8
1)
Mains voltage
U V 320 ... 528
Mains frequency
f Hz 45 ... 66
Fuse 3ph/PE
I A 6 10
UL-Type 600 VAC RK5. 3ph/PE
I A 6 10
Mechanics
Dimensions
HxWxD
mm 190x60x175 250x60x175
Weight (approx.)
m kg 1.2 1.6
Degree of protection
- - IP20 (EN60529)
Terminals
A mm
2
0.2 ... 1.5
Form of assembly
- - vertical
Ambient conditions
Energy dissipation
(2 kHz Switching frequency)
P W 40 46 58 68 68 87 115 130
Coolant temperature
T
n
°C 0 ... 40 (3K3 DIN IEC 721-3-3)
Storage temperature
T
L
°C -25 ... 55
Transport temperature
T
T
°C -25 ... 70
Rel. air humidity
- % 15 ... 85; not condensing
If required by the customer, the switching frequency may be increased if the output current is reduced at the
same time. Comply with the applicable standards and regulations for this operating point.
Output current
4)
Switching frequency
Frequency inverter nominal power
2 kHz 4 kHz 8 kHz 12 kHz 16 kHz
0.55 kW 1.8 A 1.8 A 1.8 A 1.5 A 1.2 A
0.75 kW 2.4 A 2.4 A 2.4 A 2.0 A 1.6 A
1.1 kW 3.2 A
1)
3.2 A
1)
3.2 A
1)
2.7 A
1)
2.2 A
1.5 kW
1)
3.8 A 3.8 A
3)
3.8 A
3)
3.2 A
3)
2.6 A
3)
1.85 kW 4.2 A 4.2 A 4.2 A 3.5 A 2.9 A
2.2 kW 5.8 A 5.8 A 5.8 A 4.9 A 3.9 A
3.0 kW 7.8 A
1)
7.8 A
1)
7.8 A
1)
6.6 A
1)
5.3 A
4.0 kW 9.0 A
1)
9.0 A
1) 3)
9.0 A
1) 3)
7.6 A
1) 3)
6.1 A
3)
1)
Three-phase connection requires a commutating choke.
2)
Mains current with relative mains impedance ≥ 1% (see chapter„Electrical installation“)
3)
Switching frequency is reduced in thermal limit range.
4)
Maximum current in continuous operation
