Operating Instructions ACTIVE 06/0774
74 Operating Instructions ACTIVE 06/07
7.2.5 Plausibility check
After the machine data (and the speed sensor data, if applicable) have been entered,
the calculation or examination of the parameters is started automatically. The display
changes over to "CALC" for a short time. If the verification of the machine data is
successful, the guided commissioning procedure continues with the identification of
the parameters.
Verification of the machine data should only be skipped by experienced users. The
configurations contain complex control processes which depend to a large degree on
the correctness of the machine parameters entered.
The warning and error messages displayed during the verification process have to be
observed. If a critical condition is detected during the guided commissioning, it is dis-
played by the control unit. Depending on the deviation from the expected parameter
value, either a warning or an error message is displayed.
− To ignore the warning or error messages, press the ENT key. The guided commis-
sioning is continued. However, it is recommended that the data be checked and
corrected if necessary.
− To correct the entered parameter values after the warning or error message, press
the ESC key. Use the arrow keys to switch to the parameter value which is to be
corrected.
Warning Messages
Code Measures / Remedy
SA000
No warning message present. This message can be read out via an optional
communication module.
SA001
The value of the parameter
Rated voltage 370 is out of the rated voltage
range of the frequency inverter. The maximum reference voltage is indi-
cated on the rating plate of the frequency inverter.
SA002
For a three-phase motor, the calculated efficiency is in the limit range.
Check the values entered for the parameters
Rated voltage 370, Rated
current
371 and Rated power 376.
SA003
The value entered for parameter
Rated cos phi 374 is outside of the nor-
mal range (0.6 to 0.95). Check the value.
SA004
For three-phase motor, the calculated slip is in the limit range.
Check the values entered for parameters
Rated speed 372 and Rated fre-
quency
375.
