Operating Instructions ACTIVE06/07 35
06/07 Operating Instructions ACTIVE 35
5.4 Connection of the device
5.4.1 Dimensioning of the conductor cross section
Dimension the wire according to the electrical load and applied voltage. Use a suitable
conductor cross section to reduce the voltage drop at the wire. The motor can not
obtain the full torque if the voltage drop at the wire is too high. Comply to the coun-
try-specific and application-specific regulations and to the UL-Notes. Suitable fuse
protection values for the mains connection are listed in the chapter “Technical data”.
Dimension the conductor cross section of the protective conductor (PE) according to
EN 61800-5-1:
Mains cable cross section Protective conductor (PE)
Up to 10 mm² Instal two protective conductors with the same
conductor cross section as for the mains cable or
10 mm
2
conductor cross section.
10…16 mm² Instal a protective conductor with the same con-
ductor cross section as for the mains cable.
16…35 mm² Instal a protective conductor with 16 mm² conduc-
tor cross section.
> 35 mm² Instal a protective conductor with the half cross
section of the mains cable cross section.
5.4.1.1 Typical conductor cross sections
The following tables give an overview with typical conductor cross sections (copper
cable with PVC insulation, 30 °C ambient temperature, continuous mains current
maximum 100% of rated mains current). Dependening on the operation conditions
other conductor cross sections may be applicable.
230 V: one-phase (L/N) and two-phase (L1/L2) connection
ACT 201 Mains cable PE-conductor Motor cable
-05
-07
-09
0.55 kW
0.75 kW
1.1 kW
1.5 mm²
2x1.5 mm² or
1x10 mm²
1.5 mm²
-11
-13
-15
1.5
2.2 kW
3 kW
2.5 mm²
2x2.5 mm² or
1x10 mm²
1.5 mm²
-18 4 kW 4 mm²
2x4 mm² or
1x10 mm²
4 mm²
230 V: three-phase connection (L1/L2/L3)
ACT 201 Mains cable PE-conductor Motor cable
-05
-07
-09
-11
-13
-15
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
3 kW
1.5 mm²
2x1.5 mm² or
1x10 mm²
1.5 mm²
-18
-19
4 kW
5.5 kW
4 mm²
2x4 mm² or
1x10 mm²
4 mm²
-21 7.5 kW 6 mm²
2x 6 mm² or
1x10 mm²
6 mm²
-22 9.2 kW 10 mm² 1x10 mm² 10 mm²
