Operating Instructions ACTIVE06/07 85
06/07 Operating Instructions ACTIVE 85
8.5 Control Level
The
Control level 28 defines the scope of the functions to be parameterized. The
operating instructions describe the parameters on the third control level. These pa-
rameters should only be set by qualified users.
Parameter Settings
No. Description Min. Max. Fact. sett.
28 Control Level 1 3 1
8.6 User Name
The
User name 29 can be entered via the optional control software VPlus. The plant
or machine designation cannot be displayed completely via the control unit.
32 alpha-numerical characters
8.7 Configuration
The Configuration 30 determines the assignment and basic function of the control
inputs and outputs as well as the software functions. The software of the frequency
inverters offers various configuration options. These differ with respect to the way in
which the drive is controlled. Analog and digital inputs can be combined and comple-
mented by optional communication protocols. The operating instructions describe the
following configurations and the relevant parameters in the third
Control level 28
(adjustment of parameter
Control level 28 to value 3).
Configuration 110, sensorless control
Configuration 110 contains the functions for variable-speed control of a 3-phase ma-
chine in a wide range of standard applications. The motor speed is set according to
the V/f characteristic in accordance with the voltage/frequency ratio.
Configuration 111, sensorless control with technology controller
Configuration 111 extends the functionality of the sensor-less control by software
functions for easier adaptation to the customer's requirements in different applica-
tions. Depending on the application, the technology controller may be used, which
enables the control of flow rate, pressure, contents level or speed.
