14.4.8 Fixed Value Change-Over
Depending on the selected configuration, the reference values are specified via the
assignment of the
Reference frequency source 475 or Reference percentage source
476. Accordingly, there can be a change between the fixed values by way of linking
the logic signals to the parameters
Fixed frequency change-over 1 66, Fixed fre-
quency change-over 2
67 or the parameters Fixed percent change-over 1 75, Fixed
percent change-over 2
76.
By combining the logic states of the fixed frequency change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed Frequency Control
Fixed Frequency Chan-
ge-Over 1
66
Fixed Frequency Chan-
ge-Over 2
67
Function / active fixed value
0 0
Fixed Frequency 1 480
1 0
Fixed Frequency 2 481
1 1
Fixed Frequency 3 482
0 1
Fixed Frequency 4 483
0 = contact open 1 = contact closed
By combining the logic states of the fixed percentage change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed Percentage Control
Fixed percentage value
change-over 1
75
Fixed percentage value
change-over 2
76
Function / active fixed value
0 0
Fixed Percentage 1 520
1 0
Fixed Percentage 2 521
1 1
Fixed Percentage 3 522
0 1
Fixed Percentage 4 523
0 = contact open 1 = contact closed
