13.6 Fixed Reference Values
The fixed reference values are to be parameterized as fixed frequencies or fixed per-
centages according to the configuration and function.
The signs of the fixed reference values determine the direction of rotation. A positive
sign means a clockwise rotation, a negative sign means an anticlockwise rotation. The
direction can only be changed via the sign if the
Reference Frequency Source 475 or
Reference Percentage Source 476 is parameterized to an operation mode with sign
(+/-). The direction of rotation can also be stated with the digital signal sources as-
signed to the parameters
Start Clockwise 68 and Start Anticlockwise 69.
The fixed reference values are to be parameterized in four data sets and are assigned
to further sources via the reference value channel. The use of the functions
Data Set
Change-Over 1
70 and Data Set Change-Over 2 71 thus enables the setting of 16
fixed reference values.
13.6.1 Fixed Frequencies
The four fixed frequencies define reference values which are selected via the parame-
ters
Fixed Frequency Change-Over 1 66 and Fixed Frequency Change-Over 2 67.
The parameter
Reference Frequency Source 475 defines the addition of the various
sources in the reference frequency channel.
Parameter Settings
No. Description Min. Max. Fact. sett.
480 Fixed Frequency 1 -999.99 Hz 999.99 Hz 0.00 Hz
481 Fixed Frequency 2 -999.99 Hz 999.99 Hz 10.00 Hz
482 Fixed Frequency 3 -999.99 Hz 999.99 Hz 25.00 Hz
483 Fixed Frequency 4 -999.99 Hz 999.99 Hz 50.00 Hz
By combining the logic states of the fixed frequency change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed Frequency Control
Fixed Frequency
Change-Over 1
66
Fixed Frequency
Change-Over 2
67
Function / active fixed value
0 0
Fixed Frequency 1 480
1 0
Fixed Frequency 2 481
1 1
Fixed Frequency 3 482
0 1
Fixed Frequency 4 483
0 = contact open 1 = contact closed
13.6.2 JOG-Frequency
The JOG function forms part of the functions for controlling the drive mechanism via
the control unit. Use the arrow keys to change the JOG frequency within the function.
The frequency of the output signal is set to the entered value if the FUN key is
pressed. The drive starts and the machine turns at the set
JOG-Frequency 489. If
the JOG frequency has been changed using the arrow keys, this value is stored.
Parameter Settings
No. Description Min. Max. Fact. sett.
489 JOG-Frequency -999.99 Hz 999.99 Hz 5.00 Hz
