7.2.4 Machine Data
The machine data to be entered during the guided commissioning procedure are indi-
cated on the type plate or the data sheet of the motor. The factory settings of the
machine parameters are based on the nominal data of the frequency inverter and the
corresponding four-pole three-phase motor. The entered and calculated machine data
are checked for plausibility during the guided commissioning procedure. The user
should verify the factory-set rated data of the three-phase motor.
U
FIN,
I
FIN,
P
FIN
are rated values of the frequency inverter.
Parameter Settings
No. Description Min. Max. Fact. sett.
370 Rated Voltage 0.17⋅U
FIN
2⋅U
FIN
U
FIN
371 Rated Current 0.01⋅I
FIN
10⋅o ⋅ I
FIN
I
FIN
372 Rated Speed 96 min
-1
60 000 min
-1
n
N
374 Rated Cosinus Phi 0.01 1.00 cos(ϕ)
N
375 Rated Frequency 10.00 Hz 1000.00 Hz 50.00
376 Rated mechanical power 0.01⋅P
FIN
10⋅P
FIN
P
FIN
• Use the arrow keys to select the required parameter and edit the parameter
value.
• Use the ENT key to confirm the selected parameter and the parameter values
entered.
Attention! The rated data of the motor are to be entered according to the specifica-
tions on the rating plate for the motor connection type used (star or
delta connection). If the data entered deviate from the rating plate, the
parameters will not be identified correctly. Parameterize the rated data
according to the specifications for the motor winding connection indi-
cated on the rating plate. Take the higher rated current of the connected
asynchronous motor into account.
