BONFIGLIOLI act 401 User Manual

Operating Instructions ACTIVE 06/07136
136 Operating Instructions ACTIVE 06/07
Operation mode Function
21 - Comparator 2
The comparison according to the selected
OP.
mode
Comparator 2 543 is true.
22 - Warning V-belt
Warning of
Operation Mode 581 of V-belt moni-
toring.
23 - Timer 1
The selected
Operation Mode Timer 1 790 gen-
erates an output signal of the function.
24 - Timer 2
The selected
Operation Mode Timer 2 793 gen-
erates an output signal of the function.
25 - Warning Mask
Message of the configurable parameter
Create
Warning Mask
536.
30 - Flux Formation Ended Magnetic field has been impressed.
41 - Open brake
Activation of a brake unit depending on the
Op-
eration Mode
620 for the starting behavior, Op-
eration Mode
630 for the stopping behavior or
the configured brake control system.
43 - External Fan
The
Switch-On Temperature 39 has been
reached.
60 - Arrived at desired Position
Reference orientation 469 of axle positioning
reached.
70 - Logic Function 1
Signal from output of logic module 1, according to
parameterized
Operation Mode Logic 1 198.
71 - Logic Function 2
Signal from output of logic module 2, according to
parameterized
Operation Mode Logic 2 201.
72 - Logic Function 3
Signal from output of logic module 3, according to
parameterized
Operation Mode Logic 3 205.
73 - Logic Function 4
Signal from output of logic module 4, according to
parameterized
Operation Mode Logic 4 503.
100 to 173 Operation modes inverted (LOW active).
14.3.1 Setting Frequency
If operation mode 4 is selected for a digital output, the corresponding output be-
comes active if the
Stator Frequency 210 has exceeded the value set under the pa-
rameter
Setting Frequency 510.
The relevant output is switched over again as soon as the Stator Frequency 210 falls
below the value selected for the setting frequency.
Parameter Settings
No. Description Min. Max. Fact. sett.
510 Setting Frequency 0.00 Hz 999.99 Hz 3.00 Hz
14.3.2 Reference value reached
In operation mode 5 or 6 for a digital output, a message is generated via the corre-
sponding output when the actual frequency or actual percentage value has reached
the reference value.
The maximum deviation can be defined as a percentage of the adjustable range (Max
- Min) via the parameter
Max. Control Deviation 549.
Parameter Settings
No. Description Min. Max. Fact. sett.
549 Max. Control Deviation 0.01 % 20.00 % 5.00 %
