21 Parameter List
The parameter list is structured according to the menu branches of the control unit.
The parameters are listed in ascending numerical order.. A headline (shaded) can
appear several times, i.e. a subject area may be listed at different places in the table.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
I
FIN,
U
FIN,
P
FIN
: rated values of the frequency inverter, o: overload capacity of frequency inverter
21.1 Actual Value Menu (VAL)
Actual Values of the Machine
No. Description Unit Display range Chapter
210 Stator Frequency Hz 0.00 ... 999.99 18.2
211 R.m.s Current A 0.0 ... I
max
18.2
212 Output Voltage V 0.0 ... U
FIN
18.2
213 Active Power kW 0.0 ... P
max
18.2
214 Active Current A 0.0 ... I
max
18.2
215 Isd A 0.0 ... I
max
18.2
216 Isq A 0.0 ... I
max
18.2
217 Encoder 1 Frequency Hz 0.00 ... 999.99 9.4
218 Encoder 1 Speed 1/min 0 ... 60000 9.4
221 Slip Frequency Hz 0.0 ... 999.99 18.2
Actual Values of the Frequency Inverter
222 DC link voltage V 0.0 ... U
dmax
-25 18.1
223 Modulation % 0 ... 100 18.1
Actual Values of the Machine
224 Torque Nm
± 9999.9
18.2
225 Rotor Flux % 0 ... 100 18.2
226 Winding Temperature deg.C 0 ... 999 17.7.2
227 Act. Rotor Time Constant ms
0 ...
τ
max
18.2
Actual Values of the Frequency Inverter
228 Internal Reference Frequency Hz 0.00 ... f
max
18.1
229 Reference Percentage Value %
± 300.00
18.1
230 Actual Percentage Value %
± 300.00
18.1
Actual value memory
231 Peak Value Long Term Ixt % 0.00 ... 100.00 18.3
232 Peak Value Short Term Ixt % 0.00 ... 100.00 18.3
Actual Values of the Machine
235 Flux-Forming Voltage V 0.0 ... U
FIN
18.2
236 Torque-Forming Voltage V 0.0 ... U
FIN
18.2
238 Flux Value % 0.0 ... 100.0 18.2
239 Reactive Current A 0.0 ... I
max
18.2
240 Actual Speed 1/min 0 ... 60000 18.2
241 Actual Frequency Hz 0.0 ... 999.99 18.2
Actual Values of the System
242 Actual Value System Hz 0.0 ... 999.99 18.4.1
