Operating Instructions ACTIVE06/07 205
06/07 Operating Instructions ACTIVE 205
Actual Values of the Frequency Inverter
No. Description Unit Display range Chapter
244 Working Hours Counter h 99999 18.1
245 Operation Hours Counter h 99999 18.1
249 Active Data Set - 1 ... 4 14.4.7
250 Digital Inputs - 00 ... 255 20.2
251 Analog Input MFI1A % ± 100.00 14.1.1
252 Repetition frequency input Hz 0.0 ... 999.99 13.11
254 Digital Outputs - 00 ... 255 20.2
255 Heat Sink Temperature deg.C 0 ... T
kmax
18.1
256 Inside Temperature deg.C 0 ... T
imax
18.1
257 Analog Output MFO1A V 0.0 ... 24.0 14.2.1
259 Current Error - FXXXX 18.1
269 Warnings - AXXXX 18.1
275 Controller Status - CXXXX 18.1
278 Frequency MFO1F Hz 0.00 ... f
max
14.2.2
Actual Values of the System
285 Volumetric Flow m3/h 0 ... 99999 18.4.2
286 Pressure kPa 0.0 ... 999.9 18.4.2
Actual value memory
287 Peak Value Vdc V 0.0 ... U
dmax
18.3
288 Average Value Vdc V 0.0 ... U
dmax
18.3
289 Peak Value Heat Sink Temp. deg.C 0 ... T
kmax
18.3
290 Average Value Heat Sink Temp. deg.C 0 ... T
kmax
18.3
291 Peak Value Inside Temperature deg.C 0 ... T
imax
18.3
292 Average Value Inside Temperature deg.C 0 ... T
imax
18.3
293 Peak value Irms A
0.0 ... o
⋅ I
FIN
18.3
294 Average value Irms A
0.0 ... o
⋅ I
FIN
18.3
295 Peak Value Active Power pos. kW
0.0 ... o
⋅P
FIN
18.3
296 Peak Value Active Power neg. kW
0.0 ... o
⋅P
FIN
18.3
297 Average Value Active Power kW
0.0 ... o
⋅P
FIN
18.3
301 Energy, positive kWh 0 ... 99999 18.3
302 Energy, negative kWh 0 ... 99999 18.3
Error List
310 Last Error h:m; F 00000:00; FXXXX 19.1
311 Last Error but one h:m; F 00000:00; FXXXX 19.1
312 Error 3 h:m; F 00000:00; FXXXX 19.1
313 Error 4 h:m; F 00000:00; FXXXX 19.1
314 Error 5 h:m; F 00000:00; FXXXX 19.1
315 Error 6 h:m; F 00000:00; FXXXX 19.1
316 Error 7 h:m; F 00000:00; FXXXX 19.1
317 Error 8 h:m; F 00000:00; FXXXX 19.1
318 Error 9 h:m; F 00000:00; FXXXX 19.1
319 Error 10 h:m; F 00000:00; FXXXX 19.1
320 Error 11 h:m; F 00000:00; FXXXX 19.1
321 Error 12 h:m; F 00000:00; FXXXX 19.1
322 Error 13 h:m; F 00000:00; FXXXX 19.1
323 Error 14 h:m; F 00000:00; FXXXX 19.1
324 Error 15 h:m; F 00000:00; FXXXX 19.1
325 Error 16 h:m; F 00000:00; FXXXX 19.1
