2.3 ACT 401 (18.5 up to 30.0 kW)
Scope of Supply
Scope of Supply
A
Frequency inverter
B
Terminal strip X10 (Phoenix ZEC 1.5/3ST5.0)
Plug-in terminals for the relay output
C
Standard fixtures with fixing screws (M4x20, M4x70)
for vertical assembly
D
Brief Instructions and manuals on CD
E
Control terminals X210A / X210B (Wieland DST85 / RM3.5)
Plug-in terminal for connection of the control signals
Note: Please check incoming goods for quality, quantity and nature without
delay. Obvious defects such as exterior damage of the packing and/or the
unit must be notified to the sender within seven days for insurance rea-
sons.
