Operating Instructions ACTIVE06/07 93
06/07 Operating Instructions ACTIVE 93
Attention! In configurations 210, 211 and 230, digital input S4IND is by default set
for the evaluation of a speed sensor signal (track B).
If an operation mode without sign is selected (
Operation Mode 11 or
Operation Mode 12), this input is not set for the evaluation of a speed
sensor signal and can be used for other functions.
9.4.2 Division marks, speed sensor 1
The number of increments of the connected speed sensor can be adjusted via parame-
ter
Division marks, speed sensor 1 491. Select the division marks of the speed sensor
according to the speed range of the application.
The maximum number of division marks S
max
is defined by the frequency limit of
f
max
=150 kHz of the digital inputs S5IND (track A) and S4IND (track B).
max
max
n
min/s 60
Hz 000150S ⋅=
For example:
600
0
1500
60s
Hz 150000
max
S =⋅=
f
max
=
n
max
=
150000 Hz
Max. speed of the motor in RPM
To guarantee true running of the drive, an encoder signal must be evaluated at least
every 2 ms (signal frequency f = 500 Hz). The minimum number of division marks S
min
of the incremental encoder for a required minimum speed n
min
can be calculated from
this requirement.
min
min
nA
min/s 60
Hz 500S
⋅
⋅=
For example:
1500
102
s 60
Hz 500
min
S =
⋅
⋅=
n
min
=
A =
Min. speed of the motor in RPM
Evaluation (1, 2, 4)
Parameter Settings
No. Description Min. Max. Fact. sett.
491 Division marks, speed sensor 1 1 8192 1024
