BONFIGLIOLI act 401 User Manual

Operating Instructions ACTIVE06/07 139
06/07 Operating Instructions ACTIVE 139
Operation mode Function
33 - Controller Udc Limitation
The DC link voltage has exceeded the
Reference
DC-Link Limitation
680.
34 -
Controller
Voltage Pre-Control
The
Dyn. Voltage Pre-Control 605 accelerates the
control characteristics.
35 - Controller I abs The output current is limited.
36 -
Controller
Torque Limitation
The output power or the torque is limited on the
speed controller.
37 -
Controller
Torque Control
Switch-over of field-orientated control between
speed and torque-controlled.
38 - Ramp Stop
The
Operation Mode 620 selected in starting be-
havior limits the output current.
39 -
Contr. Intel. Curr. Lim.
LT-Ixt
Overload limit of the long-term Ixt (60s) reached,
intelligent current limits active.
40 -
Contr. Intel. Curr. Lim.
ST-Ixt
Overload limit of the short-term Ixt (1s) reached,
intelligent current limits active.
41 -
Contr. Intel. Curr. Lim.
Tc
Max. heat sink temperature T
K
reached, Operation
Mode
573 for the intelligent current limits active.
42 -
Contr. Intel. Curr. Lim.
Motor Temp.
Max. motor temperature T
PTC
reached, Operation
Mode
573 for the intelligent current limits active.
43 -
Controller
Torque Limitation
The reference frequency has reached the
Maximum
Frequency
419. The frequency limitation is active.
101 to 143
Removal or deactivation of the operation mode
within the warning mask.
The selected warning mask can be read out via the parameter
Actual Warning Mask
537. The above operation modes, which can be set in the configurable
Create Warn-
ing Mask
536 are encoded in the Actual Warning Mask 537. The code results from
hexadecimal addition of the individual operation modes and the matching abbrevia-
tion.
Warning code Operation mode 536
A FFFF FFFF - 1 - Activate everything
A 0000 FFFF - 2 - Activate all Warnings
A FFFF 0000 - 3 - Activate all Controller States
A 0000 0001 Ixt 10 - Warning Ixt
A 0000 0002 IxtSt 11 - Warning Short-Term Ixt
A 0000 0004 IxtLt 12 - Warning Long-Term Ixt
A 0000 0008 Tc 13 - Warning Heat Sink Temperature
A 0000 0010 Ti 14 - Warning Inside Temperature
A 0000 0020 Lim 15 - Warning Limit
A 0000 0040 INIT 16 - Warning Init
A 0000 0080 MTemp 17 - Warning Motor Temperature
A 0000 0100 Mains 18 - Warning Phase Failure
A 0000 0200 PMS 19 - Warning Motor Protection Switch
A 0000 0400 Flim 20 - Warning Fmax
A 0000 0800 A1 21 - Warning Analog Input MFI1A
A 0000 1000 A2 22 - Warning Analog Input MFI2A
A 0000 2000 Sysbus 23 - Warning System bus
A 0000 4000 UDC 24 - Warning Udc
A 0000 8000 BELT 25 - Warning V-belt
Table "Operation Modes of Warning Mask" continued on next page.
