Operating Instructions ACTIVE06/07 211
06/07 Operating Instructions ACTIVE 211
Motor Circuit Breaker
No. Description Unit Setting range Chapter
571 Operation mode - Selection 14.2.2
572 Frequency Limit % 0 ... 300
14.2.2.1
Intelligent current limits
573 Operation mode - Selection 16.1
574 Power Limit % 40.00 ... 95.00 16.1
575 Limitation Time min 5 ... 300 16.1
Error/warning behavior
576 Phase Supervision - Selection 12.7
578 Allowed No. of Auto-Acknowl. - 0 ... 20 12.7
579 Restart Delay ms 0 ... 1000 12.8
Pulse Width Modulation
580 Reduction Limit Heat Sink Temp. deg.C -25 ... 0 17.1
V-belt Monitoring
581 Operation mode - Selection 17.6
582 Trigger Limit Iactive % 0.1 ... 100.0 17.6
583 Delay Time s 0.1 ... 600.0 17.6
V/f characteristic
600 Starting Voltage V 0.0 ... 100.0 15
601 Voltage Rise % -100 ... 200 15
602 Rise Frequency % 0 ... 100 15
603 Cut-Off Voltage V 60.0 ... 560.0 15
604 Cut-Off Frequency Hz 0.00 ... 999.99 15
605 Dyn. Voltage Pre-Control % 0 ... 200 15.1
Current limit value controller
610 Operation mode - Selection 16.4.2
611 Amplification - 0.01 ... 30.00 16.4.2
612 Integral Time ms 1 10000 16.4.2
613 Current Limit A
0.0 ... o
⋅ I
FIN
16.4.2
614 Frequency Limit Hz 0.00 ... 999.99 16.4.2
Starting Behavior
620 Operation mode - Selection 11.1.1
621 Amplification - 0.01 ... 10.00 11.1.1
622 Integral Time ms 1 ... 30000 11.1.1
623 Starting Current A
0.0 ... o
⋅ I
FIN
11.1.1.1
624 Frequency Limit Hz 0.00 ... 100.00 11.1.1.2
Stopping Behavior
630 Operation mode - Selection 11.2
Direct current brake
631 Braking Current A
0.00 ...
√2⋅I
FIN
11.3
632 Braking Time s 0.0 ... 200.0 11.3
633 Demagnetizing Time s 0.1 ... 30.0 11.3
634 Amplification - 0.00 ... 10.00 11.3
635 Integral Time ms 0 ... 1000 11.3
Stopping Behavior
637 Switch-Off Threshold % 0.0 ... 100.0 11.2.1
638 Holding Time s 0.0 ... 200.0 11.2.2
