Barcode
Barcode Settings
68
BMP71 User’s Manual
Barcode
Barcode data can be displayed in the same line as other data (text or symbols). It is not
necessary to have a separate area for the barcode. Barcode data on the same line as text will
not overwrite the text already on the line but will be placed next to it. The height of the
barcode is detemrined in the Barcode Setup function. (See “Setup Barcode” on page 29 for
more information.) Any text in the same line as the barcode will align on the baseline with the
barcode.
Barcode Settings
Field To Use
Barcode Symbology The BMP71 Label Printer supports Code 128 and Code
139 barcode symbology.
Ratio
The ratios available are 2:1 and 3:1.
Height The height of the bars in a barcode can vary, with a
minimum of 0.1 inch (2.54 mm).
Width The width of the narrow bar of a barcode is 1, 2, or 3 dots.
Human Readable Human Readable text can be placed above or below the barcode, or
you can choose to not have it displayed.
Check Digit A check digit is used for error detection in a barcode. You can turn
the check digit function on or off.
