100-214-276 Rev. 3 5-5
2000X aed Actuator Chapter 5: Technical Specifications
Instruction Manual Physical Description
Figure 5.1 2000X Actuator Pneumatic System
3
6
1
2
4
5
INPUT
EXHAUST
FLOW CONTROL VALVE
REGULATOR
COOLING
VALVE
CYLINDER
PRIMARY
MAC VALVE
TO
CARRIAGE
FILTER
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Branson 2000X Series and is the answer not in the manual?

Branson 2000X Series Specifications

General IconGeneral
Frequency20 kHz
Overload ProtectionYes
Frequency Range19.5 kHz to 20.5 kHz
Voltage50/60 Hz
Operating Temperature0 - 40° C
