REAR AXLE
KUKJE MACHINERY CO., LTD.
109
3. DISASSEMBLING AND SERVICING
2) Disassembling Rear Axle Case
*. PART NAME
1) Spring
2) Differential lock shift fork
3) Differential lock clutch
4) 57T Gear 5) Bearing
6) External snap ring 7) Rear axle
< Differential lock shift fork, differential lock
clutch(Right side only), 57T gear and rear axle >
1. Remove the spring(1).
2. Draw out the differential lock shift fork(2) and
differential lock clutch(3).
3. Remove the external snap ring(6) and remove
the bearing(5).
4. Draw out the 57T gear(4) from the rear axle(7).
5. Tap out the rear axle(7) to the outside of the rear
axle case.
