ELECTRIC SYSTEM
KUKJE MACHINERY CO., LTD.
155
<2> Components
1. Seat Switch
This switch is located under the seat. When Sitting on the seat,
the seat switch (1) is pushed in and electrical circuit is closed.
When the seat is vacant, this switch is not pushed and electric is
opened.
2. Neutral Switch
This switch is located on the transmission case upper cover.
When the main speed change lever is not in neutral, this switch is
pushed in and electrical circuits are opened.
3. Rear PTO Switch
This switch is under the PTO gear shitf lever. When the PTO
gear shitf lever is in neutral, this switch is pushed in and electric
circuit is closed.
4. Clutch Pedal Switch
This switch detects when the clutch is being depressed. When
the clutch pedal is depressed and the clutch disengaged, this
switch is pushed in and electric circuit is closed.
3. STARTING & STOPPING SYSTEM
