▷ Test 2 : Safety switch for HST of main gear
1. Fully depress the clutch pedal.
2. Depress the speed control pedal HST type or
shift the main gear shift lever Manual
transmission type to “Desired” position.
3. Turn the key to “Start” position.
4. The engine must not crank.
▷ Test 3 : Safety switch for PTO
1. Fully depress the clutch pedal.
2. Place the speed control pedal in “Neutral”
position HST type or shift the main gear shift
lever Manual transmission type to “Neutral”
position.
3. Shift the PTO gear shift lever to “On”(Engaged)
position.
4. Turn the key to “Start” position.
5. The engine must mot crank.
▷ Test 4 : Seat switch
1. Sit on operator’s seat.
2. Start the engine.
3. Fully depress the clutch pedal.
4. Shift the PTO gear shift lever to “On”(Engaged)
position.
5. Stand up. (Do not get off the machine.)
6. The engine must shut off after approximately 1
second.
7. If it does not stop, consult your local Branson
Dealer for this service.
▶ NOTE
1) If the engine cranks during nay of these tests,
adjust or replace the required safety switch.
< Greasing >
1. Apply the grease to the following position as
figures.
*. PART NAME
1) Grease fitting(HST pedal) 2) Battery terminals
3) Grease fitting (Lifting rod RH)
4) Grease fitting (Top link)
5) Front axle tie rod
7. DISASSEMBLING AND SERVICING
(4)
(3)
(5)
(2)
(1)
