CLUTCH
KUKJE MACHINERY CO., LTD.
43
4. CHECKING, DISASSEMBLEING AND SERVICING
*. PART NAME
1) Universal joint cover
2) Universal joint
3) Spring pin
4) Bearing holder
< Universal joint and bearing holder >
1. Loosen the clamp and slide the universal joint
cover(1) to the rear.
2. Remove the bearing holder(4) with the propeller
shaft and universal joint.
3. Tap out the spring pins(3) and then slide the
universal joint(2) to the rear.
▷ Reassembling
9 Apply grease to the spline of the propeller shaft
and universal joint.
9 When inserting the spring pins(3), face their
splits in the direction parallel to the universal
joint as shown in the figure.
9 Assemble the universal joint cover(1) so that the
water drain hole may become downward.
9 Arrange the position of the clamp at side as
shown in the figure.
< Hydraulic hose >
1. Remove the hydraulic hose(1) from the front
cylinder assy(2).
*. PART NAME
1) Hydraulic hose 2) Front cylinder assy
(1)
(2)
(3)
(4)
